EasyTrack3 by DATAPAQ

Easy, Efficient, Economic Profiling System

Datapaq Easytrack2




DATAPAQ EasyTrack3 is the latest generation of Oven Tracker systems in the EasyTrack family. Built on the pedigree of EasyTrack & EasyTrack2, the new system continues to provides the market with the easiest, robust, powerful oven profiling tool available to custom coaters, OEM operations or coating suppliers alike. Features:

  • Auto logger detect
  • More memory
  • On-board calibration data
  • Remote service diagnostics tool
  • Improved battery performance
  • Slope markers
  • Auto software language change

Send the DATAPAQ EasyTrack3 system through your oven and measure the product and oven temperature to guarantee that the correct time at temperature is achieved to give you the correct thermal coating cure.



FEATURES TECHNICAL DATAMORE INFO PRICE LIST

Features

Datapaq Easy Track 2 User Manual 1 3

  1. Easy Interpretation of Profile - Data Convert raw data into meaningful process information using either EasyTrack or EasyTrack Professional software. Easy-to-use but provides the power to make intelligent, confident decisions, using the industry accepted index cure analysis tool (DATAPAQ Value). Share your findings easily with either printed or digital media. Switch languages on the fly in one installation.
  2. Economic Efficient Battery - Power Single user-replaceable with locally sourced 9V battery. Battery life optimization through intelligent power management and auto power down. USB logger powering on reset & download (50 x 1 hour runs).

  3. Full Certification for Regulatory Compliance - DATAPAQ EasyTrack3 calibration certificate stored on-board allowing full traceability of equipment and each run to the last calibration data.
  4. Multiple Run Efficiency - Perform MultiRun*, allowing up to 3 sequential separate runs without need to download between ovens, saving time and effort. Download each run as a separate result file.
  5. PC-free Run 'Pass/Fail' at Oven Exit - Without need to download data, see if the profile has passed your cure targets (time at temperature) direct from the logger using SmartPaq*. It is as simple as a green light indicating 'pass' and red for 'fail', without risk of a damaged LCD.
  6. Robust Industrial Tool you Demand - Cold touch polycarbonate case designed to take knocks in the plant withstanding up to 212 °F (100 °C) without damage or distortion. Coated electronics to eliminate moisture damage even in humid working environments.
  7. Detailed Secure Profile Data - Non-volatile memory, allowing up to 2.5 hours of profile runs with a sample interval of 0.5 s, giving the resolution you need to make confident decisions. No risk of data loss even after battery replacement.
  8. Safe Transportation - Magnetic probes attach to barrier top plate for ease and safety when handling.
  9. Thermocouples Designed for Purpose - Comprehensive range designed for accuracy, ease-of-use and durability for your industrial applications. Measure with confi dence. Specified to (ANSI MC96.1 ±0.4 % or テつア2.0 °F [1.1 °C])
  10. Measurement Accuracy Given - Cold junction compensation guarantees logger accuracy over entire logger operating range up to 185 °F (85 °C). Accuracy guaranteed from start to finish of a run or day.
  11. Safe Passage Through Oven - Lockable handle ensuring secure hanging on paint line. Lockable barrier clips eliminate risk of lid loss even when accidents happen.
  12. Protection Back-Up - Heatsink phase change provides optimal thermal protection when you need it. Logger auto-shutdown above 185 °F (85 °C) to prevent damage or risk of inaccurate data collection.
  13. System Choice - Choose a 4 or 6 channel system to match process and budget (Standard, Advanced & Professional).
  14. Thermal Performance You Can Trust - Protect your logger run after run with confidence. TB0263 barrier provides up to 3 hours* protection at 392 °F (200 °C), yet only 3.7 kg (8.2 lbs), making use and transport easy and safe.
  15. Operational Simplicity for a Paint Line - Running a profile is as simple as press 'green' to start and 'red' to
    stop, and any line operator can use it with ease and without risk.

* Available with EasyTrack3 Professional system only.

Technical Data

Technical Data
Channels:4 or 6 thermocouple options
Measurement Range: -238 to 932°F (-150 to 500°C)
Thermocouple Type:K (mini-plug)
Logger accuracy±0.9°F (±0.5°C)
Cold Junction Compensation:Accuracy guaranteed with change in logger temperature
Resolution:±0.2°F (±0.1°C)
Logger Operating Range:32 to 185°F (0 to 85°C) with safe auto shut down
Case:High temperature cool touch molded polycarbonate <212°F (100°C)
PCB: Coated to improve moisture protection
Sampling Interval:0.5 s to 60min
Start Trigger: Auto start/ start button / temperature trigger
Battery Use: Replaceable 9V alkaline (ANSSI/NEDA 1604A IEC6LR61)
Battery Life:Min 360 hours continuous operation - 5 s, 6 channels 77°F (25°C)
Min 50x1 hour oven runs - 5 s, 6 channels at 158°F (70°C)
Memory: 18.000 readings per channel per run (0.5 s sample interval = 2.5 hours run time). Non volatile hot data protection.
On Board Calibration Data: Digital certificate
On Board Logger LEDs:Logger & battery status indication
On Board Logger Diagnostics:Service email for logger health check
Logger USB Power:No battery discharge on reset & download
Auto Logger Detection:Auto boot up when logger detected by Insight™ software
Multiple Run Capability*:Max 3 runs separately stored in logger
SmartPaq*:Intelligent logger profile run 'pass/fail' indicator
Computer Interface Cable: CI1150 mini-B USB connector
Hardwired Telemetry:via USB cable
Software Compatibility: EasyTrack Insight (V8.50); EasyTrack Insight Professional (V8.50)
Windows Compatibility:32 and 64-bit versions of Windows® XP, Vista, 7, 8, 10
Logger Dimension (lxwxh): 170 x 67 x 20.5mm (6.7 x 2.6 x 0.8 in)
Replaces: EasyTrack; EasyTrack2
Logger Weight:4 Channel - 196 g (0.43 lbs); 6 Channel - 200 g (0.44 lbs)
* Requires Insight Professional software

Applications

  • Custom coaters 'job shops'
  • Coating suppliers
  • Oven manufacturers
  • General industrial
  • Automotive component supply
  • Architectural coating
  • Textile coating
  • Wood coating
  • Consumer goods
  • Domestic appliance
  • Metal packaging
  • High temperature coating
  • Specialty coatings

EasyTrack Insight™ Software

The EasyTrack3 temperature profiling system comes with two choices of software; standard EasyTrack Insight or the new EasyTrack Insight Professional version.

Both software versions allow to confirm that cure temperatures meet paint manufacturers’ specifications, make comparisons probe-to-probe, identify that the Datapaq® values fall within an acceptable tolerance range and evaluate process parameter changes. With a simple click of the mouse, you can print out a profile report that will satisfy all necessary regulatory requirements.

In addition, the Professional software package unlocks some new key features of the ET3 datalogger, such as multiple run and SmartPaq operation. It also provides an enhanced analysis and reporting platform allowing a professional coating suppliers to offer efficient service to their customers.

ET3 Data Logger

The ET3 datalogger guarantees accurate temperature profiling and is designed with the easy two-button operation. Improved logger memory of x3 permits the profile detail your coating process demands (0.5 sample interval = 2.5 hours run). A battery life is improved x2.5 over the previous EasyTrack2 logger. Performing safely in up to 85°C/185°F, the plastic cool-touch case allows safe and comfortable handling even after the most demanding runs. Supplied with onboard calibration certificate, the ET3 temperature logger provides complete traceability to comply with QA standards.

Thermal Barrier

The EasyTrack3 profiling system comes with thermal barriers that guarantees robust thermal protection and continuous performance run after run.
  • The standard thermal barrier confidently provides 2 hours protection at 200°C/392°F. With weight of only 3kg/6.5 lbs and height of 110mm/4.3 in, it’s easy and safe for transportation.
  • The professional thermal barrier is designed for more demanding powder coating processes where multiple runs back to back are necessary to complete the profiling task in limited time.

Thermocouples

The EasyTrack3 system is offered with a comprehensive range of thermocouples to suit every application and product type - from universal exposed junction probe which can be taped directly to any product or material type to a compact designed Micromag probe attaching quickly directly to your steel product.

Thermocouple range offers accuracy and reliability. Quad wrapped, 10 Stand PTFE and metal braid coated type K thermocouples designed with circular cross section to reduce kinking and strong crimped plug cable attachment. Specified to ANSI MC96.1 special limits of error ±0.4 % or 1.1 °C (2.0 °F). PTFE cables are rated up to 265 °C (509 °F). Cables quoted 1.5 m (6 ft) but available in variety of lengths.

The probe is further improved by a stronger 'crimped' plug/cable attachment and a circular cable cross section to reduce kinking and twisting. The green color of the cable conforms to the IEC584 color standard for Type K thermocouples.

Exposed junction PTFEPatch probe PTFEExposed junction fiberglassMicroMag air/surface PTFEOffset magnet air/surface PTFE cableClip air/surface PTFE

Datapaq Calibration

Prices

Prices subject to change Prices listed in US dollars for domestic shipments within US, Canada, & Mexico only Export orders require quotations - click here for a quote For more info call us 1-800-762-2478 or 954-946-9454.

Fluke Datapaq

Item Number ItemPrices

For System Pricing Choose from System Options Below.
Specify 4 or 6 Channel, Probe Type 4 or 6 included (specify probes from probe list below).
Please contact us for more information or application questions.


System Options:

Standard

Advanced

Professional
4 Channel Starting Price:$4,440.004,815.005,915.00
6 Channel Starting Price:$4,780.005,355.006,455.00
Application/Use: Budget option for general paint and powder Regular basic use for general paint & powder with probe upgradeFrequent high use with multiple ovens for paint suppliers or general paint & powder. Added analysis & reporting power.
Insight Software:EasyTrack EasyTrackEasyTrack Professional
Thermal Barrier: 2 hrs @ 200°C (392°F)2 hrs @ 200°C (392°F)3 hrs @ 200°C (392°F)
Probes:Patch Clamp or magneticClamp or magnetic
Misc.:--Carry bag ID tags probe clamp
Probe Selection for EasyTrack System and OvenTracker XL2
Clamp Type K Probes
Surface Clamp
(Maximum temperature reading of 510°F/265°C)
These probes are designed for surface contact on ferrous or non-ferrous substrates, specifically aluminum. They are constructed of stainless steel throughout with a Teflon sheathed PTFE insulated ten strand wire. The self adjusting swivel jaws ensure correct sensor alignment on substrate thickness from 0.04 to 0.9 in. (1.0mm to 24.0mm).
TH-7332 Surface Clamp, K Type probe. 5 ft (1.5m) cable$279.00
TH-7333Same as above, 10 ft (3.0m) cable305.00
Ambient Air Clamp
(Maximum temperature reading of 510°F/265°C)
These probes are designed specifically for measuring ambient air temperature. They are constructed with a stainless steel outer tube with a Teflon core, stainless steel clip and an exceptionally durable, quadruple wrapped, ten strand PTFE coated wire.
TH-7334Ambient Air Clamp, K Type probe, 5 ft (1.5m) cable279.00
TH-7335 Same as above, 10 ft (3.0m) cable305.00
Magnetic Type K Probes
Magnetic Surface
(Maximum temperature reading of 510°F/265°C)
Small, yet extremely strong, these new probes give accurate and repeatable temperature readings in the tightest of recesses. with a 0.7” (17mm) footprint, state-of-the-art magnets, and an easy to grasp aluminum handle.
TH-7336Magnetic Surface, K Type probe. 5 ft (1.5m) cable279.00
TH-7337Same as above, 10 ft (3.0m) cable305.00
Magnetic Ambient Air
(Maximum temperature reading of 510°F/265°C)
These probes are designed specifically for measuring ambient air temperature. They are constructed with a stainless steel outer tube, and an exceptionally durable quad wrapped, 10 strand PTFE coated wire.
TH-7338Magnetic Ambient Air, K Type probe. 5 ft (1.5m) cable279.00
TH-7339Same as above, 10 ft (3.0m) cable305.00
MicroMag Surface & Air
With a 17mm (0.7”) state of the art Samarium Cobalt magnet, low thermal mass and an easy to handle aluminum knob, the MicroMag can be quickly and efficiently attached to ferrous substrates. Despite its compact size, the magnet strength guarantees secure attachment at the highest temperatures experienced within the paint and powder coating industry
. The MicroMag is useful in extremely tight places.
TH-7343MicroMag Surface Magnetic Thermocouple 5 ft (1.5m) cable287.00
TH-7344MicroMag Air Magnetic Thermocouple 5 ft (1.5m) cable287.00
Adhesive Patch Type K Probes
Rapid Response Light Duty Patch
These probes are recommended for all substrates <1.0mm thick and are ideal for IR processes where the probe can be placed on the substrate and then over coated. The foil thermocouple junction allows for rapid response times of 100ms. Constructed of a single strand Teflon coated wire these probes employ a self adhesive patch for attachment. They can also be used as a short duration ambient air probe where immediate response is desired.
TH-7340Rapid Response Light Duty Patch, K Type probe. 5 ft (1.5m) cable87.00
Rapid Response Heavy Duty Patch
These probes are recommended for non-ferrous substrates such as plastic or aluminum. The welded thermocouple junction allows for a rapid response time of 1 sec. They are attached to the test piece by spot-welding, soldering or use of high temperature tape. These probes can also be used in still air environments as a rapid response ambient air probe.
TH-7342Rapid Response Heavy Duty Patch, K Type probe. 6 ft (2.0m) cable93.00
TH-7341 Same as above, 10 ft (3.0m) cable109.00

Datapaq Easy Track 2 User Manual Pdf
